182mmx182mm 48V Solar Panel 540W IP68 600 Watt Solar System

Ask Lasest Price
Brand Name :	MITSCN
Certification :	ISO
Price :	Negotiable
Payment Terms :	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :	100000 Piece/Pieces per Month
Delivery Time :	5-8 working days

Add to Cart

Product Details
Company Profile

182mmx182mm 48V Solar Panel 540W IP68 600 Watt Solar System

48v 540w 550w 560w solar photovolta panel monocrystalline panel solar 600w

Product name:540w 550w 560w solar photovolta panel monocrystallin panel solar 600w
Cell size:182mmx182mm
Type:PERC, Half Cell, Bifacial, Double-glass, All Black
Panel Dimensions:2279*1134*35mm
Panel Efficiency:21.67%
Certificate:TUV/CE/IEC/ISO/INMETRO
Solar cell:A-grade
Junction Box:IP68 Rated
Connector:QC4 Compatible Connector
Color:Blue Ad Black
Front Glass:3.2mm HighTransmission
Output Cables:4.0mm2, 300/400mm in length
Maximum system Voltage:1000V/1500V DC
Application:Home Commercial Solar System
Frame:Anodized Aluminium Alloy

48v 540w 550w 560w solar photovolta panel monocrystalline panel solar 600w

Maximum Power(Pmax)	540W	545W	550W
Open-circuit Voltage (Voc)	49.8V	50V	50.2V
Maximum Power Voltage(Vmp)	42V	42.2V	42.4V
Short-circuit Current (Isc)	13.66A	13.72A	13.78A
Maximum Power Current (Imp)	12.86A	12.91A	12.97A
Solar Panel Efficiency	21.13%	21.32%	21.52%
Power Tolerance	0~+5W
Standard Test Environment	Irradiance 1000w/m2, Ambient temperature 25℃, Spectrum AM 1.5

Maximum Power(Pmax)	555W	560W
Open-circuit Voltage (Voc)	50.4V	50.6V
Maximum Power Voltage(Vmp)	42.6V	42.8V
Short-circuit Current (Isc)	13.42A	13.90A
Maximum Power Current (Imp)	13.03A	13.08A
Solar Panel Efficiency	21.48%	21.67%
Power Tolerance	0~+5W
Standard Test Environment	Irradiance 1000w/m2, Ambient temperature 25℃, Spectrum AM 1.5

Solar Panel Cell

* High output-power: conversation efficiency is 18%-22%
* High shunt-resistance: adapt the several environmental
conditions.
* Bypass diode minimizes the power drop by shade
* Excellent low light effect
* Low breakage rate

Frame

* Aluminium extrusion profile with prompt delivery
* Available in customized surface finish
* Excellent material for smooth and subtle edges
* Extrusion for construction and other industrial purposes
* Thickness variable according special request

Junction Box

* High current and voltage carrying capacity
* Simple, quick and safe effective field assembly
* IP 68 it can be used in the outdoor iron environment
* Expansion connector are available for future requirement
* Double permanent connection are adapted for all of the
connecting.
