430W N TYPE TOPCON Solar Panel 420W 425W 182mm Solar Cell

Product Categories

Beijing MITSCN Co., Ltd.

Contact Now

430W N TYPE TOPCON Solar Panel 420W 425W 182mm Solar Cell

Ask Lasest Price
Brand Name :	MITSCN
Certification :	ISO
Price :	Negotiable
Payment Terms :	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :	100000 Piece/Pieces per Month
Delivery Time :	5-8 working days

Add to Cart

Product Details
Company Profile

430W N TYPE TOPCON Solar Panel 420W 425W 182mm Solar Cell

Topcon N TYPE 430W mono solar panel half cell pv module 182mm solar cell panels

Cell size:182mmx182mm
Type:PERC, Half Cell, N-TYPE, TOPCON, mono Solar Panel
Panel Dimensions:1722*1134*35
Panel Efficiency:21%
Certificate:CE, FCC,ROHS
Cell Type:182*182mm
Weight:22kg
Frame:Anodized Aluminium Alloy
Junction Box:IP68 Rated
Voltage at Maximum power(Vmpp):31.88V
Current Maximum power(Impp):13.49A
Voc:38.49V
Isc:14.23A
Application:Industrial

Topcon N TYPE 430W mono solar panel half cell pv module 182mm solar cell panels

ELECTRICAL CHARACTERISTICS AT STC
Maximum power(Pmax)	410W	420W	425W	430W
Open Circuit Voltage(Voc)	37.73V	38.11V	38.30V	38.49V
Short Circuit Current(Isc)	13.91A	14.07A	14.15A	14.23A
Voltage at Maximum power(Vmpp)	31.13V	31.51V	31.70V	31.88V
Current Maximum power(Impp)	13.17A	13.33A	13.41A	13.49A
MODULE EFFICIENCY(%)	21.00%	21.51%	21.76%	22.02%
Operating Temperature	-40°C to +85°C
Maximum System Voltage	1000VDC (IEC)
Fire Resistance Rating	Type 1(in accordance with 1703)/Class C(IEC61730)
Maximum Series Fuse Rating	25A
MECHANICAL CHARACTERISTICS
Cell type	N type
Number of cells	108(6x18)
Module dimensions	1730x1134x35mm
Weight	22kg
Front cover	3.2mm,Anti-Reflflection Coating,Tempered Glass
Frame	Anodized Aluminium Alloy
Junction box	IP68 Rated
Cable	TÜV 1×4.0mm2,Length:300mm or Customized Length
Connector	PV Connector (compatible)
TEMPERATURE CHARACTERISTICS
Nominal Operating Cell Temperature (NOCT)			45°C±2°C
Temperature Coeffiffifficients of Pmax			-0.38%/℃
Temperature Coeffiffifficients of Voc			-0.31%/℃
Temperature Coeffiffifficients of Isc			0.06%/℃
PACKAGING
Standard packaging			31pcs/pallet
Module quantity per 20’container			324pcs
Module quantity per 40’container			806pcs(HQ)
